CabinetSeals
Dennard Cabinet seals are manufactured in different polymer combinations such as Epdm , Epdm & PVC and Epdm sponge to suit various sealing requirements of electrical enclosures and cabinets.
Sponge and Solid EPDM, with a unique wire carrier and tongue shape buckle. The cabinet seals are fitted on the edges of the metal , plastic or fibreglass enclosures. The seals will ensure an effective barrier against dust , water , exposure to ice , chemicals , oil and UV. These seals are designed to ensure the weatherproofing against outdoor environmental conditions.
Dennard Cabiner seals has a very low permanent compression set and is resistant to a wide temperature range from -50 to +120.
TechnicalData
Specificaties | Details |
---|---|
Hardness – Dense Epdm | 70 ± 5 |
Tensile Strength Kg / cm² | 70 Min |
Elongation at Break | 300 Min |
Compression set at 70° for 22 hrs | 50 Max |
Ozone resistance | No cracks |
Specific Gravity – Sponge Epdm | 0.55 ± 0.05 |
Insertion force in kgs / 100 mm flange width | > 5 kg in a 2 mm sheet |
Retention force in kg / 100 mm flange width | > 5 kg in a 2 mm sheet |
Compression load in gms / 100 mm flange width | 600 ~ 900 in 2 mm height |
